Description
Display
| Screen diagonal | 15.0 ″ |
| Permission | 1024×768 |
| Brightness | 420 cd/m2 |
| Backlight life time | 30000 time. |
| Contrast | 800:1 |
| Chroma | 262K |
| Matrix type | TFT |
| Viewing angle | 160(Horizontal) /160(Vertical) |
Sensor
| Sensor type | Projected-capacitive |
| Sensor interface | USB |
| Sensor Light Transmission | Over 90% |
Options
| Chipset | SoC |
| Number of RAM slots | 1 |
| OZU | 8000 Mb |
| The maximum possible amount of RAM | 16000 Mb |
| RAM type | DDR4 SODIMM |
| Space for hard drives | 1 |
| Drive form factor | 2.5 ″ |
| drive interface | SATA3 HDD |
| Audio | Realtek ALC269Q HD audio codec |
Interfaces
| Serial interface | 1 x M12 8pin for COM 1, 1xR232/RS422/RS485, default RS-232 with waterproof cover |
| USB host | 1 x M12 8-pin for USB 2.0 with waterproof cover |
| PCI | 1 x miniPCIe slot for Wifi/BT (optional), 4G/LTE (optional) |
| Power connector | 1 x M12 3-pin DC |
| RFID | RFID (Radio Frequency Identification) for authorization in the system (optional) |
Construction
| Corpus material | Stainless steel body (304, optional 316) |
| Degree of protection of the front panel | IP66 / IP69K |
| Net weight) | 7 kg |
| Wall mount VESA 75 | VESA 75×75 |
| Installation options | VESA 75×75, Yoke mount (optional) |
PO
| Operating system | Windows 7 64 bit, Windows 8 64 bit, Windows 10 IoT 64 bit |
Operation and storage
| Working temperature | -20~50%°C |
| Power | 35 W |
| Relative Humidity | 10 to 90% at 40°C, non-condensing |
APLEX ViTAM-915AP Panel Computer Dimensions
Dimensions: 399 x 324 x 53 mm
